RLW08

Customer to give  details when ordering.



       See Page 14 for eye type

　

　

　 　
Art.No Working
load limited		 Approx thickness Approx width Minimum length Maximum length Eye length Weight/meter
5:1 6:1 7:1 5:1 6:1 7:1
W08-02 2000 15 25 25 30 1.1 100 400 0.34 0.45 0.49
W08-04 4000 15 50 50 60 1.2 100 500 0.64 0.78 0.81
W08-06 6000 15 75 75 90 1.3 100 600 1.04 1.18 1.24
W08-08 8000 15 100 100 120 1.4 100 700 1.34 1.4 1.66
W08-10 10000 15 125 125 150 1.5 100 800 1.65 1.72 2.03
W08-12 12000 15 150 150 180 1.8 100 900 1.95 2.03 2.31
W08-16 16000 15 200 200 240 2.0 100 950 2.26 2.6 2.77
W08-20 20000 15 250 250 300 2.4 100 1000 2.97 3.32 3.55
W08-24 24000 15 300 300 -- 2.4 100 1000 3.86 4.2 4.44
